Learn MoreSpecifications
| Type | Description | |
|---|---|---|
| Efficiency Type S.P. Level (dB) | 100 |
|
| Efficiency Testing | 1 W / 0.1 m |
|
| Nominal Input (W) | 2 |
|
| Max Input (W) | 2.5 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 550 |
|
| Enclosure | Recommended |
|
| Mounting Style | Wire Leads |
|
| Cone Type | PET |
|
| Magnet Type | Nd-Fe-B |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 34.8 x 34.8 x 5.2 |
|
| Dimensions LxWxH (in) | 1.37 x 1.37 x 0.2 |
|
| Series | CMS-3652-28XX |
|
| IP Rating | No IP Rating |
|
