HDMI Connectors

Same Sky’s line of HDMI connectors offers Type A receptacle versions conforming to the HDMI 2.0 standard. Available in surface mount, mid mount SMT, or through hole mounting styles, our HDMI connectors feature 40 Vdc voltage ratings, 0.5 A current ratings, mating cycle ratings of 10,000 cycles, and operating temperature ranges from -40 up to 100°C.

Reset All
Filters | Reset All
Results 8
Reset All
Mounting Style
dropdn-arrow
Mid-Surface Mount
Surface Mount
Through Hole
Reset
Orientation
dropdn-arrow
Horizontal
Vertical
Reset
Results 8
Show
Model Number Mounting Style Orientation HDMI Standard Number of Contacts Number of Ports Voltage Rating (Vdc) Current Rating (A) Termination Mating Cycles Operating Temp Range (°C) Connector Type HDMI Type
HD11-19-MSMT-TR HD11-19-MSMT-TR
HDMI 2.0, Receptacle Connector, 19 Positions, Horizontal, Mid-Surface Mount
Datasheet HD11-19-MSMT-TR Datasheet Stock Check HD11-19-MSMT-TR Stock Check
Mid-Surface Mount Horizontal HDMI 2.0 19 1 40 0.5 PCB 10000 -40 ~ 85 Receptacle Type A
HD06-19-RVS-MSMT-TR HD06-19-RVS-MSMT-TR
HDMI 2.0, Receptacle Connector, 19 Positions, Horizontal, Mid-Surface Mount
Datasheet HD06-19-RVS-MSMT-TR Datasheet Stock Check HD06-19-RVS-MSMT-TR Stock Check
Mid-Surface Mount Horizontal HDMI 2.0 19 1 40 0.5 PCB 10000 -40 ~ 85 Receptacle Type A
HD10-19-MSMT-TR HD10-19-MSMT-TR
HDMI 2.0, Receptacle Connector, 19 Positions, Horizontal, Mid-Surface Mount
Datasheet HD10-19-MSMT-TR Datasheet Stock Check HD10-19-MSMT-TR Stock Check
Mid-Surface Mount Horizontal HDMI 2.0 19 1 40 0.5 PCB 10000 -40 ~ 85 Receptacle Type A
HD07-19-RVS-MSMT-TR HD07-19-RVS-MSMT-TR
HDMI 2.0, Receptacle Connector, 19 Positions, Horizontal, Reversed, Mid-Surface Mount
Datasheet HD07-19-RVS-MSMT-TR Datasheet Stock Check HD07-19-RVS-MSMT-TR Stock Check
Mid-Surface Mount Horizontal HDMI 2.0 19 1 40 0.5 PCB 10000 -40 ~ 85 Receptacle Type A
HD12-19-SMT-TR HD12-19-SMT-TR
HDMI 2.0, Receptacle Connector, 19 Positions, Vertical, Surface Mount
Datasheet HD12-19-SMT-TR Datasheet Stock Check HD12-19-SMT-TR Stock Check
Surface Mount Vertical HDMI 2.0 19 1 40 0.5 PCB 10000 -40 ~ 100 Receptacle Type A
HD09-19-MSMT-TR HD09-19-MSMT-TR
HDMI 2.0, Receptacle Connector, 19 Positions, Horizontal, Mid-Surface Mount
Datasheet HD09-19-MSMT-TR Datasheet Stock Check HD09-19-MSMT-TR Stock Check
Mid-Surface Mount Horizontal HDMI 2.0 19 1 40 0.5 PCB 10000 -25 ~ 85 Receptacle Type A
HD08-19-RVS-MSMT-TR HD08-19-RVS-MSMT-TR
HDMI 2.0, Receptacle Connector, 19 Positions, Horizontal, Reversed, Mid-Surface Mount
Datasheet HD08-19-RVS-MSMT-TR Datasheet Stock Check HD08-19-RVS-MSMT-TR Stock Check
Mid-Surface Mount Horizontal HDMI 2.0 19 1 40 0.5 PCB 10000 -25 ~ 85 Receptacle Type A
HD05-19-TH-TR HD05-19-TH-TR
HDMI 2.0, Receptacle Connector, 19 Positions, Horizontal, Through Hole
Datasheet HD05-19-TH-TR Datasheet Stock Check HD05-19-TH-TR Stock Check
Through Hole Horizontal HDMI 2.0 19 1 40 0.5 PCB 10000 -25 ~ 85 Receptacle Type A
