Ultrasonic Transmitters

Used to convert electrical signals into ultrasonic waves, Same Sky’s ultrasonic transmitters carry distance ratings up to 18 meters, frequency ratings from 23 to 40 kHz, and 60-, 75- or 80-degree beam angles. Our ultrasonic transmitters are available in compact aluminum or plastic cases featuring through hole, wire leads, or wire leads with connector mounting styles, rated voltages from 60 to 200 Vp-p, and operating temperatures from -40 up to 85°C.

Reset All

Filters | Reset All

Stacked Scrolling

Results 19

Reset All

Range (m)

0 ~ 12

0 ~ 13

0 ~ 15

0.2 ~ 12

0.2 ~ 15

0.2 ~ 18

Reset

Frequency (kHz)

30.5

Reset

Voltage Rating (Vp-p)

Min

Max

150

160

180

200

Reset

Directivity (°)

Reset

Case Type

Aluminum

Plastic

Reset

Operating Temp MIN (°C)

≤ -30

≤ -20

Reset

Operating Temp MAX (°C)

≥ 70

≥ 80

≥ 85

Reset

Length (mm)

9.8

12.5

16.5

Reset

Width (mm)

9.8

12.5

16.5

Reset

Height (mm)

Min

Max

9.5

15.2

Reset

Product Release New Products

Purchase Buy Online at sameskydevices.com Normally Stocked in Distribution

Resources 3D Model Available PCB Footprint Available

Results 19

of ?

Model Number	Mounting Style	Function	Range (m)	Frequency (kHz)	Voltage Rating (Vp-p)	Directivity (°)	Case Type	Enclosed	Technology	Operating Temp Range (°C)	Length (mm)	Width (mm)	Height (mm)	Dimensions LxWxH (mm)	Data Sheet
CUSA-T80-130-3000-TH 16 mm, 200 Vp-p, 80° Directivity, 0~13 M Range, 30.5 kHz, Through Hole, Ultrasonic Transmitter Sensor Datasheet Stock Check	Through Hole	Transmitter	0 ~ 13	30.5	200	80	Aluminum	No	Analog	-20 ~ 80	16	16	12	16 x 16 x 12	CUSA-T80-130-3000-TH.pdf
CUSA-T80-120-2200-W 9.8 mm, 160 Vp-p, 80° Directivity, 0~12 M Range, 30.5 kHz, Wire Leads, Ultrasonic Transmitter Sensor Datasheet Stock Check	Wire Leads	Transmitter	0 ~ 12	30.5	160	80	Aluminum	No	Analog	-20 ~ 80	9.8	9.8	7	9.8 x 9.8 x 7	CUSA-T80-120-2200-W.pdf
CUSA-T80-120-2200-WC 9.8 mm, 160 Vp-p, 80° Directivity, 0~12 M Range, 30.5 kHz, Wire Leads w/ Connector, Ultrasonic Transmitter Sensor Datasheet Stock Check	Wire Leads with Connector	Transmitter	0 ~ 12	30.5	160	80	Aluminum	No	Analog	-20 ~ 80	9.8	9.8	7	9.8 x 9.8 x 7	CUSA-T80-120-2200-WC.pdf
CUSA-T80-130-3000-W 16 mm, 200 Vp-p, 80° Directivity, 0~13 M Range, 30.5 kHz, Wire Leads, Ultrasonic Transmitter Sensor Datasheet Stock Check	Wire Leads	Transmitter	0 ~ 13	30.5	200	80	Aluminum	No	Analog	-20 ~ 80	16	16	12	16 x 16 x 12	CUSA-T80-130-3000-W.pdf
CUSA-T75-120-2200-TH 12.5 mm, 160 Vp-p, 75° Directivity, 0~12 M Range, 30.5 kHz, Through Hole, Ultrasonic Receiver Sensor Datasheet Stock Check	Through Hole	Transmitter	0 ~ 12	30.5	160	75	Aluminum	No	Analog	-20 ~ 80	12.5	12.5	9.5	12.5 x 12.5 x 9.5	CUSA-T75-120-2200-TH.pdf
CUSA-T75-120-2200-W 12.5 mm, 160 Vp-p, 75° Directivity, 0~12 M Range, 30.5 kHz, Wire Leads, Ultrasonic Receiver Sensor Datasheet Stock Check	Wire Leads	Transmitter	0 ~ 12	30.5	160	75	Aluminum	No	Analog	-20 ~ 80	12.5	12.5	9.5	12.5 x 12.5 x 9.5	CUSA-T75-120-2200-W.pdf
CUSA-T80-130-3000-WC 16 mm, 200 Vp-p, 80° Directivity, 0~13 M Range, 30.5 kHz, Wire Leads w/ Connector, Ultrasonic Transmitter Sensor Datasheet Stock Check	Wire Leads with Connector	Transmitter	0 ~ 13	30.5	200	80	Aluminum	No	Analog	-20 ~ 80	16	16	12	16 x 16 x 12	CUSA-T80-130-3000-WC.pdf
CUSA-T80-120-2200-TH 9.8 mm, 160 Vp-p, 80° Directivity, 0~12 M Range, 30.5 kHz, Through Hole, Ultrasonic Transmitter Sensor Datasheet Stock Check	Through Hole	Transmitter	0 ~ 12	30.5	160	80	Aluminum	No	Analog	-20 ~ 80	9.8	9.8	7	9.8 x 9.8 x 7	CUSA-T80-120-2200-TH.pdf
CUSA-T75-120-2200-WC 12.5 mm, 160 Vp-p, 75° Directivity, 0~12 M Range, 30.5 kHz, Wire Leads w/ Connector, Ultrasonic Receiver Sensor Datasheet Stock Check	Wire Leads with Connector	Transmitter	0 ~ 12	30.5	160	75	Aluminum	No	Analog	-20 ~ 80	12.5	12.5	9.5	12.5 x 12.5 x 9.5	CUSA-T75-120-2200-WC.pdf
CUSA-T601-150-2400-TH 24 mm, 60 Vp-p, 60° Directivity, 0~15 m Range, 25 kHz, Through Hole, Ultrasonic Transmitter Sensor Datasheet Stock Check	Through Hole	Transmitter	0 ~ 15	25	60	60	Aluminum	No	Analog	-20 ~ 80	24	24	14	24 x 24 x 14	CUSA-T601-150-2400-TH.pdf
CUSA-T60-150-2400-TH 24 mm, 60 Vp-p, 60° Directivity, 0~15 m Range, 40 kHz, Through Hole, Ultrasonic Transmitter Sensor Datasheet Stock Check	Through Hole	Transmitter	0 ~ 15	40	60	60	Aluminum	No	Analog	-20 ~ 80	24	24	14	24 x 24 x 14	CUSA-T60-150-2400-TH.pdf
CUSP-T80-18-2400-TH 16.5 mm, 150 Vp-p, 80° Directivity, 0.2~18 m Range, 40 kHz, Through Hole, Ultrasonic Transmitter Sensor Datasheet Stock Check	Through Hole	Transmitter	0.2 ~ 18	40	150	80	Plastic	No	Analog	-20 ~ 70	16.5	16.5	12	16.5 x 16.5 x 12	CUSP-T80-18-2400-TH.pdf
CUSP-T80-12-2600-TH 12.5 mm, 180 Vp-p, 80° Directivity, 0.2~12 m Range, 25 kHz, Through Hole, Ultrasonic Transmitter Sensor Datasheet Stock Check	Through Hole	Transmitter	0.2 ~ 12	25	180	80	Plastic	No	Analog	-30 ~ 85	16	16	12	16 x 16 x 12	CUSP-T80-12-2600-TH.pdf
CUSP-T80-15-2400-TH 9.8 mm, 80 Vp-p, 80° Directivity, 0.2~15 m Range, 40 kHz, Through Hole, Ultrasonic Transmitter Sensor Datasheet Stock Check	Through Hole	Transmitter	0.2 ~ 15	40	80	80	Plastic	No	Analog	-20 ~ 80	9.8	9.8	7	9.8 x 9.8 x 7	CUSP-T80-15-2400-TH.pdf
CUSA-T80-18-2400-TH 16.0 mm, 150 Vp-p, 80° Directivity, 0.2~18 m Range, 40 kHz, Through Hole, Ultrasonic Transmitter Sensor Datasheet Stock Check	Through Hole	Transmitter	0.2 ~ 18	40	150	80	Aluminum	No	Analog	-20 ~ 70	16	16	12	16 x 16 x 12	CUSA-T80-18-2400-TH.pdf
CUSA-T80-12-2600-TH 16.0 mm, 180 Vp-p, 80° Directivity, 0.2~12 m Range, 25 kHz, Through Hole, Ultrasonic Transmitter Sensor Datasheet Stock Check	Through Hole	Transmitter	0.2 ~ 12	25	180	80	Aluminum	No	Analog	-30 ~ 85	16	16	12	16 x 16 x 12	CUSA-T80-12-2600-TH.pdf
CUSA-T80-12-2200-TH 16.0 mm, 150 Vp-p, 80° Directivity, 0.2~12 m Range, 23 kHz, Through Hole, Ultrasonic Transmitter Sensor Datasheet Stock Check	Through Hole	Transmitter	0.2 ~ 12	23	150	80	Aluminum	No	Analog	-30 ~ 85	16	16	21	16 x 16 x 21	CUSA-T80-12-2200-TH.pdf
CUSA-T75-18-2400-TH 12.5 mm, 80 Vp-p, 75° Directivity, 0.2~18 m Range, 40 kHz, Through Hole, Ultrasonic Transmitter Sensor Datasheet Stock Check	Through Hole	Transmitter	0.2 ~ 18	40	80	75	Aluminum	No	Analog	-30 ~ 85	12.5	12.5	15.2	12.5 x 12.5 x 15.2	CUSA-T75-18-2400-TH.pdf
CUSA-T80-15-2400-TH 9.8 mm, 80 Vp-p, 80° Directivity, 0.2~15 m Range, 40 kHz, Through Hole, Ultrasonic Transmitter Sensor Datasheet Stock Check	Through Hole	Transmitter	0.2 ~ 15	40	80	80	Aluminum	No	Analog	-20 ~ 80	9.8	9.8	14	9.8 x 9.8 x 14	CUSA-T80-15-2400-TH.pdf
