Learn MoreSpecifications
| Type | Description | |
|---|---|---|
| Enclosure | Recommended |
|
| S.P. Level (dB) | 93 (0.4 W / 0.1 m) |
|
| IP Rating | No IP Rating |
|
| Max Input (W) | 0.6 |
|
| Nominal Input (W) | 0.4 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 800 |
|
| Cone Type | PEN |
|
| Magnet Type | Nd-Fe-B |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 16 x 16 x 3.2 |
|
| Dimensions LxWxH (in) | 0.63 x 0.63 x 0.13 |
|
| Mounting Style | Solder Pads |
|
