Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 92 (1 W / 0.5 m) |
|
| Max Input (W) | 5 |
|
| Nominal Input (W) | 3 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 125 |
|
| Cone Type | Paper |
|
| Magnet Type | Ferrite |
|
| Frame Shape | Square |
|
| Dimensions LxWxH (mm) | 120 x 120 x 44 |
|
| Dimensions LxWxH (in) | 4.72 x 4.72 x 1.73 |
|
| Mounting Style | Solder Eyelet(s) |
|
