Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 90 (1 W / 0.5 m) |
|
| Max Input (W) | 30 |
|
| Nominal Input (W) | 25 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 80 |
|
| Cone Type | Paper |
|
| Magnet Type | Ferrite |
|
| Frame Shape | Square |
|
| Dimensions LxWxH (mm) | 114 x 114 x 51.3 |
|
| Dimensions LxWxH (in) | 4.49 x 4.49 x 2.02 |
|
| Mounting Style | Solder Eyelet(s) |
|
