Specifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 88 (1 W / 0.5 m) |
|
| Max Input (W) | 2 |
|
| Nominal Input (W) | 1 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 350 |
|
| Cone Type | PET |
|
| Magnet Type | Ferrite |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 77 x 77 x 21.2 |
|
| Dimensions LxWxH (in) | 3.03 x 3.03 x 0.83 |
|
| Mounting Style | Solder Eyelet(s) |
|
