GF0501

GF0501

50 mm, Round Frame, 0.25 W, 8 Ohm, Ferrite Magnet, Paper Cone, Speaker

Datasheet

Amplify Your Innovation!


Need a team of sound specialists to optimize your design's audio system? From speaker enclosures to custom audio solutions and more, Same Sky's industry-leading audio design services are here to help.

Learn More

Specifications

Type Description
Select
Enclosure Recommended
S.P. Level (dB) 87 (0.25 W / 0.5 m)
IP Rating No IP Rating
Max Input (W) 0.5
Nominal Input (W) 0.25
Impedance (Ohms) 8
Resonance Freq. (Hz) 430
Cone Type Paper
Magnet Type Ferrite
Frame Shape Round
Dimensions LxWxH (mm) 50 x 50 x 17.5
Dimensions LxWxH (in) 1.97 x 1.97 x 0.69
Mounting Style Solder Eyelet(s)

Technical Docs

Datasheet 3D Model
