Learn MoreSpecifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 94 (5 W / 0.5 m) |
|
| Nominal Input (W) | 5 |
|
| Max Input (W) | 8 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 280 |
|
| Enclosure | Recommended |
|
| Mounting Style | Solder Eyelet(s) |
|
| Cone Type | PET |
|
| Magnet Type | Ferrite |
|
| Frame Shape | Square |
|
| Dimensions LxWxH (mm) | 102 x 102 x 37 |
|
| Dimensions LxWxH (in) | 4.01 x 4.01 x 1.45 |
|
| IP Rating | No IP Rating |
|
