Learn MoreSpecifications
| Type | Description | |
|---|---|---|
| S.P. Level (dB) | 96 (5 W / 0.5 m) |
|
| Nominal Input (W) | 5 |
|
| Max Input (W) | 8 |
|
| Impedance (Ohms) | 4 |
|
| Resonance Freq. (Hz) | 200 |
|
| Enclosure | Recommended |
|
| Mounting Style | Solder Eyelet(s) |
|
| Cone Type | Paper |
|
| Magnet Type | Ferrite |
|
| Frame Shape | Square |
|
| Dimensions LxWxH (mm) | 102 x 102 x 36.5 |
|
| Dimensions LxWxH (in) | 4.02 x 4.02 x 1.44 |
|
| IP Rating | No IP Rating |
|
