Learn MoreSpecifications
| Type | Description | |
|---|---|---|
| Efficiency Type S.P. Level (dB) | 90 |
|
| Efficiency Testing | 5 / 1 |
|
| Nominal Input (W) | 5 |
|
| Max Input (W) | 6.2 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 480 |
|
| Mounting Style | Solder Eyelet(s) |
|
| Cone Type | PEI |
|
| Magnet Type | Nd-Fe-B |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 57 x 57 x 15.5 |
|
| Dimensions LxWxH (in) | 2.24 x 2.24 x 0.61 |
|
| Series | CDS-5715-58X-X7 |
|
| IP Rating | IPX7 |
|
Technical Docs
DatasheetAll Speakers Categories
