Learn MoreSpecifications
| Type | Description | |
|---|---|---|
| Enclosure | Recommended |
|
| S.P. Level (dB) | 120 (0.001 W / 0.01 m) |
|
| IP Rating | No IP Rating |
|
| Max Input (W) | 0.15 |
|
| Nominal Input (W) | 0.03 |
|
| Impedance (Ohms) | 32 |
|
| Resonance Freq. (Hz) | 220 |
|
| Cone Type | PET |
|
| Magnet Type | Nd-Fe-B |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 29.8 x 29.8 x 6 |
|
| Dimensions LxWxH (in) | 1.17 x 1.17 x 0.24 |
|
| Mounting Style | Solder Pads |
|
