Learn MoreSpecifications
| Type | Description | |
|---|---|---|
| Efficiency Type S.P. Level (dB) | 106 |
|
| Efficiency Testing | 2 / 0.1 |
|
| Nominal Input (W) | 2 |
|
| Max Input (W) | 2.5 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 550 |
|
| Mounting Style | Wire Leads |
|
| Cone Type | PEI |
|
| Magnet Type | Nd-Fe-B |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 40 x 40 x 6.5 |
|
| Dimensions LxWxH (in) | 1.57 x 1.57 x 0.26 |
|
| Series | CMS-4065-28X |
|
| IP Rating | No IP Rating |
|
Technical Docs
DatasheetAll Speakers Categories
