Learn MoreSpecifications
| Type | Description | |
|---|---|---|
| Efficiency Type S.P. Level (dB) | 87 |
|
| Efficiency Testing | 3 / 1 |
|
| Nominal Input (W) | 3 |
|
| Max Input (W) | 4 |
|
| Impedance (Ohms) | 4 |
|
| Resonance Freq. (Hz) | 650 |
|
| Mounting Style | Solder Eyelet(s) |
|
| Cone Type | PEN |
|
| Magnet Type | Nd-Fe-B |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 40 x 40 x 12 |
|
| Dimensions LxWxH (in) | 1.57 x 1.57 x 0.47 |
|
| Series | CMS-4021H-34X |
|
| IP Rating | No IP Rating |
|
