Learn MoreSpecifications
| Type | Description | |
|---|---|---|
| Efficiency Type S.P. Level (dB) | 105 |
|
| Efficiency Testing | 2 W / 0.1 m |
|
| Nominal Input (W) | 2 |
|
| Max Input (W) | 2.5 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 700 |
|
| Enclosure | Recommended |
|
| Mounting Style | Solder Pad |
|
| Cone Type | PEI |
|
| Magnet Type | Nd-Fe-B |
|
| Frame Shape | Oval |
|
| Dimensions LxWxH (mm) | 36.2 x 20.5 x 5.4 |
|
| Dimensions LxWxH (in) | 1.425 x 0.807 x 0.212 |
|
| Series | CMS-36205-28X |
|
| IP Rating | No IP Rating |
|
Technical Docs
DatasheetAll Speakers Categories
