Learn MoreSpecifications
| Type | Description | |
|---|---|---|
| Efficiency Type S.P. Level (dB) | 95 |
|
| Efficiency Testing | 1 W / 0.1 m |
|
| Nominal Input (W) | 1 |
|
| Max Input (W) | 1.2 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 500 |
|
| Enclosure | Recommended |
|
| Cone Type | PEEK |
|
| Magnet Type | Nd-Fe-B |
|
| Frame Shape | Rectangular |
|
| Mounting Style | Solder Pads |
|
| Dimensions LxWxH (in) | 0.71 x 0.51 x 0.1 |
|
| IP Rating | No IP Rating |
|
| Dimensions LxWxH (mm) | 18 x 13 x 2.5 |
|
