Specifications
Type | Description | |
---|---|---|
S.P. Level (dB) | 86 (1 W / 0.5 m) |
|
Max Input (W) | 2 |
|
Nominal Input (W) | 1 |
|
Impedance (Ohms) | 8 |
|
Resonance Freq. (Hz) | 550 |
|
Cone Type | Paper |
|
Magnet Type | Nd-Fe-B |
|
Frame Shape | Round |
|
Dimensions LxWxH (mm) | 30 x 30 x 3 |
|
Dimensions LxWxH (in) | 1.18 x 1.18 x 0.12 |
|
Mounting Style | Solder Pads |
|
