Specifications
| Type | Description | |
|---|---|---|
| Enclosure | Not Required |
|
| S.P. Level (dB) | 89 (1 W / 0.5 m) |
|
| Max Input (W) | 1.5 |
|
| Nominal Input (W) | 1 |
|
| Impedance (Ohms) | 8 |
|
| Resonance Freq. (Hz) | 650 |
|
| Cone Type | Paper |
|
| Magnet Type | Nd-Fe-B |
|
| Frame Shape | Round |
|
| Dimensions LxWxH (mm) | 23 x 23 x 5.7 |
|
| Dimensions LxWxH (in) | 0.91 x 0.91 x 0.22 |
|
| Mounting Style | Solder Pads |
|
