Specifications
| Type | Description | |
|---|---|---|
| Buzzer Type | Audio Transducer |
|
| Sound Pressure (dB) | 105 |
|
| Voltage Rating | 12 |
|
| Input Type | Vp-p |
|
| Curr. Consumption (mA) | 15 |
|
| Mounting Style | Through Hole |
|
| Shape | Round |
|
| Driving Circuit | No |
|
| Washable | No |
|
| Operating Temp Range (°C) | -40 ~ 85 |
|
| Dimensions LxWxH (mm) | 51.5 x 51.5 x 15.2 |
|
| IP Rating | No IP Rating |
|
