USB Connectors

Same Sky’s USB connectors line incorporates Type A, Type B, Micro AB, Micro B, Mini AB, Mini B, and Type C USB connector types conforming to a variety of USB standards, including 2.0, 3.2 Gen 1 (previously USB 3.1 Gen 1), 3.2 Gen 2 (previously USB 3.1 Gen 2), 3.2 Gen 2x2 (previously USB 3.2), and USB4 20 or 40 Gbps. With data transfer speeds up to 40 Gbps and power delivery up to 240 W, these USB connectors can plug into virtually any design. Power-only models with power delivery up to 90 W are also available.

Reset All

Filters | Reset All

Stacked Scrolling

Results 9

Reset All

Connector Type

Plug

Receptacle

Reset

Mounting Style

Board Edge

Cable

Hybrid Mount

Mid Mount Hybrid

Mid Mount SMT

Surface Mount

Surface Mount, Anchor Pins

Through Hole

Reset

Contact Pin Type

Hybrid Mount

Surface Mount

Through Hole

Reset

USB Type

Micro AB

Micro B

Mini AB

Mini B

Type A

Type B

Type C

Reset

Orientation

Horizontal

Right Angle

Right Angled

Vertical

Reset

USB Standard

N/A - Power Only

USB 2.0

USB 3.2 Gen 1

USB 3.2 Gen 2x1

USB 3.2 Gen 2x2

USB4

Reset

Data Transfer Speed

10 Gbps

20 Gbps

40 Gbps

480 Mbps

5 Gbps

N/A - Power Only

Reset

Voltage Rating

Reset

Input Type

Vac

Vdc

Reset

Current Rating (A)

1.5

1.8

Reset

Contact Plating Thickness

1 µin

10 µin (min)

15 µin (min)

2 µin (min)

3 µin

3 µin (min)

30 µin (min)

6 µin (min)

Gold Flash

Reset

Color Insulator

Black

Blue

White

Reset

Length (mm)

Min

Max

2.8

2.96

3.06

3.16

3.8

4.1

4.2

4.3

4.5

4.6

5.1

5.6

5.86

5.95

6.35

6.41

6.5

6.54

6.8

6.84

6.9

7.2

7.35

7.36

7.6

7.85

7.9

8.2

8.25

8.55

8.65

8.94

8.95

9.1

9.17

9.2

9.25

9.34

9.35

9.45

9.47

9.65

9.69

9.75

9.8

9.87

10.4

10.65

10.77

10.85

11.3

11.8

12.85

13.6

13.61

13.7

13.82

14.11

14.3

14.55

14.6

15.5

16.4

16.5

16.95

18.8

19.3

Reset

Width (mm)

Min

Max

3.76

4.3

5.06

7.2

7.5

8.1

8.45

8.5

8.65

8.66

8.74

8.75

8.8

8.94

8.95

8.96

8.97

9.1

9.16

9.2

9.3

9.47

9.5

9.64

9.65

9.66

9.7

9.74

9.79

9.8

9.85

9.88

9.93

9.96

10.1

10.38

10.8

10.84

11.15

11.2

11.24

11.3

11.34

11.54

11.6

11.9

12.15

12.2

12.75

12.8

13.1

14.15

14.3

14.5

14.8

15.1

15.7

16.1

16.4

Reset

Height (mm)

Min

Max

1.06

1.08

1.18

1.25

1.3

1.39

1.42

1.43

1.45

1.56

1.65

2.16

2.3

2.36

2.39

2.45

2.5

2.62

2.7

2.8

2.95

3.16

3.21

3.26

3.31

3.36

3.42

3.46

3.49

3.57

3.61

3.71

3.91

3.96

4.2

4.3

4.46

4.5

4.54

4.65

5.2

5.75

6.4

6.5

6.8

6.88

6.94

7.12

7.48

7.78

7.8

8.5

8.8

8.94

9.04

9.2

9.82

9.97

10.4

10.7

10.8

11.1

11.67

13.2

13.3

14.5

14.95

15.05

16.1

16.17

16.2

36.25

Reset

IP Rating

IP67

No IP Rating

IP68

IPX5

IPX6

IPX7

IPX8

Reset

Series

UJ2

UJ2-ADH-TH

UJ2-AH-SMT

UJ2-AV-SMT-TR

UJ2-AV-SMT-TR |

UJ2-AV-TH

UJ2-BH-TH

UJ2-MABH-SMT

UJ2-MBH-SMT

UJ20

UJ3

UJ31

UJ31-CH-SMT

UJ32

UJ40

UJC

UP2-AH-TH

UP20

UP3

UP31

UP32

Reset

Product Release New Products

Purchase Buy Online at sameskydevices.com Normally Stocked in Distribution

Resources 3D Model Available PCB Footprint Available

Results 9

of ?

Model Number	Connector Type	Mounting Style	Contact Pin Type	USB Type	Orientation	USB Standard	Data Transfer Speed	Voltage Rating	Input Type	Current Rating (A)	Contact Plating Thickness	Color Insulator	Length (mm)	Width (mm)	Height (mm)	Dimensions LxWxH (mm)	IP Rating	Series	Data Sheet
UJ32-C-H-G-SMT-TR Type C, USB 3.2 Gen 2x2, 20 Gbps, 20 Vac, 5 A, Right Angle, Gold Flash, Surface Mount, Black Insulator, USB Receptacle Datasheet Stock Check	Receptacle	Surface Mount	--	Type C	Horizontal	USB 3.2 Gen 2x2	20 Gbps	20	Vac	5	Gold Flash	Black	--	--	--	--	--	--	UJ32-C-H-G-SMT-TR.pdf
UJ32-C-H-G-L2-SMT-TR Type C, USB 3.2 Gen 2x2, 20 Gbps, 20 Vdc, 5 A, Horizontal, Hybrid Mount Mounting Style, Hybrid Mount Contact Pin Type, Gold Flash, 24 Pins, USB Receptacle Datasheet Stock Check	Receptacle	Hybrid Mount	Hybrid Mount	Type C	Horizontal	USB 3.2 Gen 2x2	20 Gbps	20	Vdc	5	Gold Flash	Black	8.65	9.65	3.42	--	--	UJ32	UJ32-C-H-G-L2-SMT-TR.pdf
UJ32-C-H-G-MSMT-TR Type C, USB 3.2 Gen 2x2, 20 Gbps, 20 Vdc, 5 A, Horizontal, Mid Mount Hybrid Mounting Style, Hybrid Mount Contact Pin Type, Gold Flash, 24 Pins, USB Receptacle Datasheet Stock Check	Receptacle	Mid Mount Hybrid	Hybrid Mount	Type C	Horizontal	USB 3.2 Gen 2x2	20 Gbps	20	Vdc	5	Gold Flash	Black	10	12.15	2	--	--	UJ32	UJ32-C-H-G-MSMT-TR.pdf
UJ32-C-H-G-L1-MSMT-TR Type C, USB 3.2 Gen 2x2, 20 Gbps, 20 Vdc, 5 A, Horizontal, Mid Mount Hybrid Mounting Style, Hybrid Mount Contact Pin Type, Gold Flash, Recessed Lip, 24 Pins, USB Receptacle Datasheet Stock Check	Receptacle	Mid Mount SMT	--	Type C	Horizontal	USB 3.2 Gen 2x2	20 Gbps	20	Vdc	5	Gold Flash	Black	9.45	11.6	2.39	--	--	UJ32	UJ32-C-H-G-L1-MSMT-TR.pdf
UJ32-C-H-G-H1-SMT-TR Type C, USB 3.2 Gen 2x2, 20 Gbps, 20 Vdc, 5 A, Horizontal, Hybrid Mount Mounting Style, Hybrid Mount Contact Pin Type, Gold Flash, 24 Pins, USB Receptacle Datasheet Stock Check	Receptacle	Hybrid Mount	Hybrid Mount	Type C	Horizontal	USB 3.2 Gen 2x2	20 Gbps	20	Vdc	5	Gold Flash	Black	8.65	9.65	3.71	--	--	UJ32	UJ32-C-H-G-H1-SMT-TR.pdf
UJ32-C-H-G-SMT-TR-68 Type C, USB 3.2 Gen 2x2, 20 Gbps, 20 Vdc, 5 A, Horizontal, Hybrid Mount Mounting Style, Hybrid Mount Contact Pin Type, Gold Flash, 24 Pins, IP68, USB Receptacle Datasheet Stock Check	Receptacle	Hybrid Mount	Hybrid Mount	Type C	Horizontal	USB 3.2 Gen 2x2	20 Gbps	20	Vdc	5	Gold Flash	Black	10.65	9.74	3.46	--	IP68	UJ32	UJ32-C-H-G-SMT-TR-68.pdf
UJ32-C-H-G-H3-MSMT-TR Type C, USB 3.2 Gen 2x2, 20 Gbps, 20 Vdc, 5 A, Horizontal, Mid Mount Hybrid Mounting Style, Hybrid Mount Contact Pin Type, Gold Flash, 24 Pins, USB Receptacle Datasheet Stock Check	Receptacle	Mid Mount Hybrid	Hybrid Mount	Type C	Horizontal	USB 3.2 Gen 2x2	20 Gbps	20	Vdc	5	Gold Flash	Black	8.65	12.15	2	--	--	UJ32	UJ32-C-H-G-H3-MSMT-TR.pdf
UJ32-C-H-G-H2-SMT-TR Type C, USB 3.2 Gen 2x2, 20 Gbps, 20 Vdc, 5 A, Horizontal, Hybrid Mount Mounting Style, Hybrid Mount Contact Pin Type, Gold Flash, 24 Pins, USB Receptacle Datasheet Stock Check	Receptacle	Hybrid Mount	Hybrid Mount	Type C	Horizontal	USB 3.2 Gen 2x2	20 Gbps	20	Vdc	5	Gold Flash	Black	10	9.65	3.42	--	--	UJ32	UJ32-C-H-G-H2-SMT-TR.pdf
UJ32-C-V-G-SMT-TR Type C, USB 3.2 Gen 2x2, 20 Gbps, 20 Vdc, 5 A, Vertical, Surface Mount Anchor Pins Mounting Style, Surface Mount Contact Pin Type, Gold Flash, 15.05 mm, 24 Pins, USB Receptacle Datasheet Stock Check	Receptacle	Surface Mount, Anchor Pins	Surface Mount	Type C	Vertical	USB 3.2 Gen 2x2	20 Gbps	20	Vdc	5	Gold Flash	Black	6.41	13.1	15.05	--	--	UJ32	UJ32-C-V-G-SMT-TR.pdf
