UJ2-A-HR-G-V-TH
Type A, USB 2.0, 480 Mbps, 5 Vdc, 1.5 A, Right Angle, Through Hole Mounting Style, Through Hole Contact Pin Type, Right Angled, Gold Flash, Board Lock, 4 Pin, USB Receptacle
Specifications
| Type | Description | |
|---|---|---|
| Connector Type | Receptacle |
|
| Mounting Style | Through Hole |
|
| Contact Pin Type | Through Hole |
|
| USB Type | Type A |
|
| Orientation | Right Angled |
|
| USB Standard | USB 2.0 |
|
| Data Transfer Speed | 480 Mbps |
|
| Voltage Rating | 5 |
|
| Input Type | Vdc |
|
| Current Rating (A) | 1.5 |
|
| Contact Plating Thickness | Gold Flash |
|
| Color Insulator | Black |
|
| Series | UJ2 |
|
