Specifications
| Type | Description | |
|---|---|---|
| Buzzer Type | Audio Transducer |
|
| Sound Pressure (dB) | 85 |
|
| Voltage Rating | 24 |
|
| Input Type | Vp-p |
|
| Curr. Consumption (mA) | 80 |
|
| Mounting Style | Wire Leads |
|
| Shape | Round |
|
| Driving Circuit | No |
|
| Washable | No |
|
| Operating Temp Range (°C) | -30 ~ 70 |
|
| Dimensions LxWxH (mm) | 32.5 x 32.5 x 8 |
|
| IP Rating | No IP Rating |
|
