Specifications
| Type | Description | |
|---|---|---|
| Buzzer Type | Audio Transducer |
|
| Driving Circuit | No |
|
| Sound Pressure (dB) | 100 |
|
| Voltage Rating | 12 |
|
| Input Type | Vdc |
|
| Curr. Consumption (mA) | 20 |
|
| Operating Temp Range (°C) | -30 ~ 100 |
|
| Mounting Style | Through Hole |
|
| Dimensions LxWxH (mm) | 30.6 x 30.6 x 16 |
|
| Shape | Round |
|
| Dimensions LxWxH (in) | 1.2 x 1.2 x 0.63 |
|
| Washable | No |
|
| IP Rating | No IP Rating |
|
| Special Features | No Special Features |
|
| Series | N/A |
|
