Specifications
| Type | Description | |
|---|---|---|
| Buzzer Type | Audio Transducer |
|
| Driving Circuit | No |
|
| Sound Pressure (dB) | 85 |
|
| Voltage Rating | 5 |
|
| Input Type | Vo-p |
|
| Curr. Consumption (mA) | 80 |
|
| Mounting Style | Through Hole |
|
| Shape | Round |
|
| Dimensions LxWxH (mm) | 25 x 25 x 12.5 |
|
| Dimensions LxWxH (in) | 0.98 x 0.98 x 0.49 |
|
| Operating Temp Range (°C) | -30 ~ 70 |
|
| Washable | Yes |
|
| IP Rating | No IP Rating |
|
