Specifications
| Type | Description | |
|---|---|---|
| Buzzer Type | Audio Indicator |
|
| Sound Pressure (dB) | 100 |
|
| Voltage Rating | 12 |
|
| Input Type | Vdc |
|
| Curr. Consumption (mA) | 50 |
|
| Mounting Style | Through Hole |
|
| Shape | Round |
|
| Illumination | No |
|
| Driving Circuit | Yes |
|
| Washable | No |
|
| Operating Temp Range (°C) | -20 ~ 60 |
|
| Dimensions LxWxH (mm) | 26.1 x 26.1 x 22.1 |
|
| Special Features | No Special Features |
|
| IP Rating | No IP Rating |
|
| Rated Frequency (Hz) | 2800 |
|
