Same Sky’s line of RF connectors offers SMA connector types in plug or receptacle versions. These RF connectors carry frequency ranges from 0 up to 26.5 GHz, nominal impedance ratings of 50 Ω, voltage standing wave ratios from 1.15 to 1.5, and working voltages of 335 Vrms. Available with standard or reverse polarity and horizontal or vertical orientations, these models feature a variety of mounting styles and contact terminations. Same Sky’s RF connectors further conform to the MIL-C-39012, MIL-PRF-39012 equivalent, and CECC 22110/111 standards, ensuring compatibility and reliable mating. IP rated RF connector models are also available.
