CBM-7530BF-240-454-20
24 V, 0.23 A, 75.7 x 75.7 x 30, Tachometer Signal, Dc Centrifugal Blower
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 13.61 |
|
| Rated Speed (RPM) | 4000 |
|
| Air Flow (m³/min) | 0.385 |
|
| Static Pressure (inH2O) | 0.64 |
|
| Noise (dBA) | 48.1 |
|
| Voltage Rating (Vdc) | 24 |
|
| Max Input Current (mA) | 230 |
|
| Rotation Detector | No |
|
| Tachometer Signal | Yes |
|
| PWM Control Signal | No |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Dimensions LxWxH (mm) | 75.7 x 75.7 x 30 |
|
| Series | CBM-75BF |
|
