CBM-7530CF-230-404-20
24 V, 0.14 A, 75.7 x 75.7 x 30 mm, Tachometer Signal, omniCOOL™ Dc Centrifugal Blower
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this centrifugal blower bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 10.14 |
|
| Rated Speed (RPM) | 3000 |
|
| Static Pressure (inH2O) | 0.33 |
|
| Noise (dBA) | 40.4 |
|
| Voltage Rating (Vdc) | 24 |
|
| Max Input Current (mA) | 140 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 75.7 x 75.7 x 30 |
|
| Series | CBM-75CF |
|
