CBM-7530BF-120-282-20
12 V, 110 mA, 75 x 75 x 30 mm, Dc Centrifugal Blower, Tachometer Signal
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 6.59 |
|
| Air Flow (m³/min) | 0.187 |
|
| Rated Speed (RPM) | 2000 |
|
| Static Pressure (inH2O) | 0.14 |
|
| Noise (dBA) | 28.2 |
|
| Voltage Rating (Vdc) | 12 |
|
| Max Input Current (mA) | 110 |
|
| Rotation Detector | No |
|
| Tachometer Signal | Yes |
|
| PWM Control Signal | No |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Dimensions LxWxH (mm) | 75 x 75 x 30 |
|
| Series | CBM-75BF |
|
| IP Rating | No IP Rating |
|
