CBM-5015CF-045-348-22

CBM-5015CF-045-348-22

5 V, 0.21 A, 51.6 x 51.2 x 15 mm, Tachometer Signal, PWM Control Signal, omniCOOL™ Dc Centrifugal Blower

Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this centrifugal blower bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.

Datasheet

Specifications

Type Description
Select
Bearing Type omniCOOL™
Air Flow (CFM) 2.85
Rated Speed (RPM) 4500
Static Pressure (inH2O) 0.45
Noise (dBA) 34.8
Rated Voltage (Vdc) 5
Max Input Current (mA) 210
Tachometer Signal Yes
Rotation Detector No
PWM Control Signal Yes
Dimensions LxWxH (mm) 51.6 x 51.2 x 15
Series CBM-50CF

Technical Docs

Datasheet 3D Model
