Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 3.49 |
|
| Rated Speed (RPM) | 5500 |
|
| Static Pressure (inH2O) | 0.67 |
|
| Noise (dBA) | 39.1 |
|
| Rated Voltage (Vdc) | 5 |
|
| Max Input Current (mA) | 300 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 51.6 x 51.2 x 15 |
|
| Series | CBM-50BF |
|
