CFM-A225BG-415-267-20
48 Vdc, 30 mA, 120 x 120 x 25 mm, Ball Bearing, Dc Fan, Tachometer Signal
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 51.75 |
|
| Air Flow (m³/min) | 1.465 |
|
| Rated Speed (RPM) | 1500 |
|
| Static Pressure (inH2O) | 0.08 |
|
| Noise (dBA) | 26.7 |
|
| Voltage Rating (Vdc) | 48 |
|
| Max Input Current (mA) | 60 |
|
| Tachometer Signal | Yes |
|
| PWM Control Signal | No |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Dimensions LxWxH (mm) | 120 x 120 x 25 |
|
| Series | CFM-A2BG |
|
| IP Rating | No IP Rating |
|
| Rotation Detector | No |
|
