CFM-5015CG-030-186

CFM-5015CG-030-186

5 V, 70 mA, 50 x 50 x 15 mm, omniCOOL, Dc Fan

Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this axial fan bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.

Datasheet

Specifications

Type Description
Select
Bearing Type omniCOOL™
Air Flow (CFM) 6.89
Rated Speed (RPM) 3000
Static Pressure (inH2O) 0.07
Noise (dBA) 18.56
Voltage Rating (Vdc) 5
Max Input Current (mA) 110
Tachometer Signal No
PWM Control Signal No
Dimensions LxWxH (mm) 50 x 50 x 15
IP Rating No IP Rating
Series CFM-50CG
Rotation Detector No
