Specifications
| Type | Description | |
|---|---|---|
| Output Type | Analog |
|
| Directivity | Omnidirectional |
|
| Port Location | Top |
|
| Sensitivity (dB) | -42 |
|
| Sensitivity Tolerance (dB) | ±3 |
|
| Sensitivity Reduction (dB) | -3 |
|
| Curr. Consumption (µA) | 500 |
|
| Operating Voltage (Vdc) | 2 |
|
| Operating Freq. (Hz) | 100 ~ 10000 |
|
| Signal : Noise Ratio (dBA) | 60 |
|
| Output Impedance (KΩ) | 2.2 |
|
| Termination | Wire Leads |
|
| Shape | Round |
|
| Wire Length (mm) | 15 |
|
| Dimensions LxWxH (mm) | 4.6 x 4.6 x 1.8 |
|
| Dimensions LxWxH (in) | 0.18 x 0.18 x 0.07 |
|
| IP Rating | No IP Rating |
|
| Series | CMEJ-4618-42-LX |
|
