Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 180.36 |
|
| Rated Speed (RPM) | 3800 |
|
| Static Pressure (inH2O) | 0.55 |
|
| Noise (dBA) | 56.4 |
|
| Voltage Rating (Vdc) | 24 |
|
| Max Input Current (mA) | 1000 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 120 x 120 x 38 |
|
| Series | CFM-A2BJ |
|
