Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 235.1 |
|
| Air Flow (m³/min) | 6.657 |
|
| Rated Speed (RPM) | 7000 |
|
| Static Pressure (inH2O) | 1.89 |
|
| Noise (dBA) | 66.2 |
|
| Voltage Rating (Vdc) | 48 |
|
| Max Input Current (mA) | 1070 |
|
| Tachometer Signal | No |
|
| PWM Control Signal | No |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Dimensions LxWxH (mm) | 120 x 120 x 38 |
|
| Series | CFM-120BF |
|
| IP Rating | No IP Rating |
|
| Rotation Detector | No |
|
