Features
| High fan speed for greater air flow |
| Dual ball bearing construction |
| Auto restart protection standard on all models |
| 120 x 120 mm frame |
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 200.9 |
|
| Rated Speed (RPM) | 4600 |
|
| Static Pressure (inH2O) | 0.78 |
|
| Noise (dBA) | 61.5 |
|
| Voltage Rating (Vdc) | 12 |
|
| Max Input Current (mA) | 1750 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 120 x 120 x 38 |
|
| Series | CFM-120 |
|
