CFM-A225BF-420-336-20
48 Vdc, 40 mA, 120 x 120 x 25 mm, Ball Bearing, Dc Fan, Tachometer Signal
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 65.21 |
|
| Air Flow (m³/min) | 1.847 |
|
| Rated Speed (RPM) | 2000 |
|
| Static Pressure (inH2O) | 0.18 |
|
| Noise (dBA) | 33.6 |
|
| Voltage Rating (Vdc) | 48 |
|
| Max Input Current (mA) | 60 |
|
| Tachometer Signal | Yes |
|
| PWM Control Signal | No |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Dimensions LxWxH (mm) | 120 x 120 x 25 |
|
| Series | CFM-120BF |
|
| IP Rating | No IP Rating |
|
| Rotation Detector | No |
|
