Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 88.3 |
|
| Rated Speed (RPM) | 6500 |
|
| Static Pressure (inH2O) | 1.04 |
|
| Noise (dBA) | 53.5 |
|
| Voltage Rating (Vdc) | 24 |
|
| Max Input Current (mA) | 420 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 92 x 92 x 38 |
|
| Series | CFM-92BF |
|
