CFM-8038BF-460-463-20
48 Vdc, 150 mA, 80 x 80 x 38 mm, Ball Bearing, Dc Fan, Tachometer Signal
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 49.8 |
|
| Rated Speed (RPM) | 6000 |
|
| Static Pressure (inH2O) | 0.89 |
|
| Noise (dBA) | 46.3 |
|
| Voltage Rating (Vdc) | 48 |
|
| Max Input Current (mA) | 230 |
|
| Tachometer Signal | Yes |
|
| PWM Control Signal | No |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Dimensions LxWxH (mm) | 80 x 80 x 38 |
|
| IP Rating | No IP Rating |
|
| Rotation Detector | No |
|
Technical Docs
