CFM-8032B-160-539-22
12 Vdc, 760 mA, 80 x 80 x 32 mm, Ball Bearing, Dc Fan, Tachometer Signal, PWM Control Signal
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 72.22 |
|
| Rated Speed (RPM) | 6000 |
|
| Static Pressure (inH2O) | 0.85 |
|
| Noise (dBA) | 53.9 |
|
| Voltage Rating (Vdc) | 12 |
|
| Max Input Current (mA) | 910 |
|
| Tachometer Signal | Yes |
|
| PWM Control Signal | Yes |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Dimensions LxWxH (mm) | 80 x 80 x 32 |
|
| IP Rating | No IP Rating |
|
| Rotation Detector | No |
|
