Features
| 80 x 80 mm frame |
| Multiple speed options for different cooling needs |
| Dual ball bearing construction |
| Tachometer signal available |
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Dimensions LxWxH (mm) | 80 x 80 x 15 |
|
| Series | CFM-80BF |
|
| Air Flow (CFM) | 34.85 |
|
| Max Input Current (mA) | 210 |
|
| Noise (dBA) | 30.1 |
|
| PWM Control Signal | No |
|
| Rated Speed (RPM) | 3000 |
|
| Rotation Detector | No |
|
| Static Pressure (inH2O) | 0.1 |
|
| Tachometer Signal | Yes |
|
| Voltage Rating (Vdc) | 24 |
|
