CFM-7015C-130-295-22
12 V, 110 mA, 70 x 70 x 15 mm, Dc Fan, Tachometer Signal, PWM Control Signal
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 19.26 |
|
| Air Flow (m³/min) | 0.545 |
|
| Rated Speed (RPM) | 3000 |
|
| Static Pressure (inH2O) | 0.08 |
|
| Noise (dBA) | 29.5 |
|
| Voltage Rating (Vdc) | 12 |
|
| Max Input Current (mA) | 110 |
|
| Rotation Detector | No |
|
| Tachometer Signal | No |
|
| PWM Control Signal | Yes |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Dimensions LxWxH (mm) | 70 x 70 x 15 |
|
| Series | CFM-70C |
|
| IP Rating | No IP Rating |
|
