CFM-7010B-140-347-20
12 V, 220 mA, 70 x 70 x 10 mm, Ball Bearing, Dc Fan, Tachometer Signal
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 24.87 |
|
| Rated Speed (RPM) | 4000 |
|
| Static Pressure (inH2O) | 0.11 |
|
| Noise (dBA) | 34.7 |
|
| Voltage Rating (Vdc) | 12 |
|
| Max Input Current (mA) | 330 |
|
| Tachometer Signal | Yes |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 70 x 70 x 10 |
|
| IP Rating | No IP Rating |
|
| Rotation Detector | No |
|
