Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 56.77 |
|
| Air Flow (m³/min) | 1.608 |
|
| Rated Speed (RPM) | 13000 |
|
| Static Pressure (inH2O) | 1.98 |
|
| Noise (dBA) | 60.6 |
|
| Voltage Rating (Vdc) | 24 |
|
| Max Input Current (mA) | 960 |
|
| Rotation Detector | No |
|
| Tachometer Signal | No |
|
| PWM Control Signal | No |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Dimensions LxWxH (mm) | 60 x 60 x 25 |
|
| Series | CFM-60BG |
|
| IP Rating | No IP Rating |
|
