CFM-5020C-275-416-20
24 V, 110 mA, 50 x 50 x 20 mm, Tachometer Signal, omniCOOL™ Dc Fan
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this axial fan bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 22.78 |
|
| Rated Speed (RPM) | 7500 |
|
| Static Pressure (inH2O) | 0.41 |
|
| Noise (dBA) | 41.6 |
|
| Voltage Rating (Vdc) | 24 |
|
| Max Input Current (mA) | 170 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 50 x 50 x 20 |
|
| Series | CFM-50C |
|
