Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 22.78 |
|
| Rated Speed (RPM) | 7500 |
|
| Static Pressure (inH2O) | 0.41 |
|
| Noise (dBA) | 41.6 |
|
| Voltage Rating (Vdc) | 24 |
|
| Max Input Current (mA) | 170 |
|
| Tachometer Signal | No |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Dimensions LxWxH (mm) | 50 x 50 x 20 |
|
| Series | CFM-50B |
|
