CFM-4020CF-155-212-20
12 V, 60 mA, 40 x 40 x 20 mm, Tachometer Signal, omniCOOL™ Dc Fan
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this axial fan bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 6.88 |
|
| Static Pressure (inH2O) | 0.14 |
|
| Rated Speed (RPM) | 5500 |
|
| Noise (dBA) | 21.2 |
|
| Dimensions LxWxH (mm) | 40 x 40 x 20 |
|
| Rated Voltage (Vdc) | 12 |
|
| Max Input Current (mA) | 90 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | No |
|
| Series | CFM-40CF |
|
