Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | Ball |
|
| Air Flow (CFM) | 9.38 |
|
| Air Flow (m³/min) | 0.266 |
|
| Rated Speed (RPM) | 7500 |
|
| Static Pressure (inH2O) | 0.25 |
|
| Noise (dBA) | 30.6 |
|
| Voltage Rating (Vdc) | 12 |
|
| Max Input Current (mA) | 170 |
|
| Rotation Detector | No |
|
| Tachometer Signal | No |
|
| PWM Control Signal | No |
|
| Operating Temp Range (°C) | -10 ~ 70 |
|
| Dimensions LxWxH (mm) | 40 x 40 x 20 |
|
| Series | CFM-40BF |
|
| IP Rating | No IP Rating |
|
