CFM-4015C-145-176-22
12 V, 50 mA, 40 x 40 x 15 mm, Tachometer Signal, PWM Control Signal, Dc Fan
Thanks to the innovative omniCOOL™ system that provides improved performance and longer operational life, this axial fan bridges the cost-performance gap between conventional sleeve and ball bearing fan designs.
Specifications
| Type | Description | |
|---|---|---|
| Bearing Type | omniCOOL™ |
|
| Air Flow (CFM) | 5.02 |
|
| Rated Speed (RPM) | 4500 |
|
| Static Pressure (inH2O) | 0.1 |
|
| Noise (dBA) | 17.6 |
|
| Voltage Rating (Vdc) | 12 |
|
| Max Input Current (mA) | 80 |
|
| Tachometer Signal | Yes |
|
| Rotation Detector | No |
|
| PWM Control Signal | Yes |
|
| Dimensions LxWxH (mm) | 40 x 40 x 15 |
|
| Series | CFM-40C |
|
